CTD D20R Double Mitre Saw

Please note: This machine is no longer being manufactured. See CTD D45 as an alternative.

CTD MODEL D20R A revolutionary idea--right and left saw heads, individually operated on a common base. Gives you a fast, accurate double mitre cut-off that beats anything in it's price class in the world.

Manufacturer's Information:

Standard Features and Specifications:

• • Blade Capacity: 12" OD (305mm); saw blades not included.

• • Spindle & Pivot: Both mounted on pre-loaded and sealed bearings; uses our time tested 200R Series saw head; saw arm, pivot brackets and table are precision machined and ground steel plate and iron.

• • Arbor: 1" (25.4mm) with 2-1/2" (64mm) saw collars; 3700 RPM of spindle.

• • Motors & Voltages:  1 H.P. single phase, 115 Volt, Totally Enclosed Fan Cooled Motors with toggle switch and plug; each motor draws 15 amps at 115 Volt; completely enclosed 2-belt drive; 230 Volt with Dual Magnetic Starter available.

• • Floor Stand: Close coupled heavy gage steel floor stand with removable dust and scrap drawer; Rabbet Measuring System included.

• • Actuation: Manual hand operation of independent saw heads.

• • Size & Weight: 46" (117cm) Wide x 22" (56cm) front to back x 56" (142cm) High"; Weight 300 lbs. (136 kg).

• • Production Rate: Up to five frames per minute; actual production rates vary with the type and width of material to be cut.

• • Dust Collection & Scrap: The D20R is provided with a dust and scrap drawer; most of the dust and chips will fall into this drawer; empty as needed; 4" (102mm) dust outlet available; 600 CFM required.

• • Cutting Capacity: 3" (76.2mm) High x 5-3/4" (146mm) Wide on non-ferrous metals, wood, and plastic sections
