Equipment Lot: Cassese CS969 Double Miter Saw, Pistorius MN-200 Double Miter Saw, Inglet Verdi Basic 96" Panel Saw, & Curtis 10HP Compressors

UE-101422D-1 Cassese CS969 Double Miter Saw

(SOLD)

Includes SmartStop programmable measuring system.

***Manufacturer's Information:

The CS 969 Automatic Double Mitre Saw is part of the new generation of saws from Cassese. Taller, wider cuts, heavy-duty and reliable, safe, clean and precise. The CS 969 is the best automatic waste reduction saw available.

Cutting Features:

- Cuts up to 160mm (6 3/8”) wide mouldings and up to 110mm (4 3/8") high mouldings
- Horizontal & raised cutting stroke allows to cut the widest mouldings without any chipping
- Alternates the cut of the blade to reduce waste to zero, saving meters of moulding
- Able to cut wooden, MDF, or plastic moulding. Ideal for industrial or craft use
- Unique "raised blade stroke" above the cutting table allows an angle of cutting toward the interior of the profile, eliminating the possibility of chipping and bad finishing
- Additional pneumatic and retractable measuring stop allows for a quick switch between short and long cuts
- 4 Pneumatic clamps (2 horizontal and 2 vertical) flatten the moulding if bent and ensure that the moulding cannot move or rock during the cutting operation
- Available in 380V or 220V triple phase

Construction & Engineering Features:

- Solid build & heavy duty design: weighing 621kg, CS 969 is designed and engineered with a focus on durability, reliability and safety
- Concrete base to absorb vibrations and get perfect cuts
- Cast aluminum cutting heads for maximum reliability and minimum maintenance
- Ducted extraction at blades dramatically reduces dust by extracting it at the source
- Oversized blade collars eliminate any possible blade flex and get perfect and accurate cuts
- Reinforced bearings ensure high quality cuts and durability

Safety Features:

- High degree of safety. Due to the unique motor brake system, brakes will stop in less than 2 seconds
- CE certified and approved. Safety built-in. Meets tough European CE safety standards, totally enclosed, two-button operation keeps hands away from blades.
- Totally enclosed for clean operation. Dust extraction at the blades and easy chip clean-out help keep saw clean. meets EU Health & Safety Regulation for Dust Collection (less than 0.1mg/ m3)
- Los noise carbide blades 350mm (14") With noise reduction technology (Z27230)
- Convenient blade-change system allow for easy positioning of blades for safe and comfortable access
- High visibility with hardened plastic windows
- Minimal dust (2 integrated extraction points)

Additional Technical Data

Power Requirements:
- 220v Triple Phase (16 Amps)
- Air Supply: 90 PSI (2 liters/cycle)
Dimensions: Height: 53" x Depth: 41 3/4" (30" without panels) x Length: 134"
Weight: 1,543 lbs
Cutting Capacity: 6 3/8" Wide x 4 3/8" Tall
Motor & Speed: 1.5kW (2hp) each; 2,800 RPM single phase - 3,200 RPM 3 phase
Optional Accessories:
- Right and left vertical clamps (Z15730)
- 1 meter right hand measuring arm extension (2.5 meters measured cut) (Z15731)
- 2 meter right hand measuring arm extension (3.5 meters measured cut) (Z15732)
- Special clamps for aluminum and thin wood (Z16005)

UE-101422D-2 Pistorius MN-200 Double Miter Saw

***Manufacturer's Information:

Pistorius Model MN-200 for cutting wood, aluminum, plastics and fiberglass

Specifications:

- Blade Capacity: 12"
- Blade Arbors: 5/8"
- Maximum Cutting Height: 2-5/8"
- Maximum Cutting Width: 3-3/8"
- Motor HP: 1.5(Each)
- Electrical: 220/440V(Wired 220)/3PH2-5/8"
- Max. height & 3-5/16" max. width cap,
- (2) 1.5HP,
- 230/460V,
- 3,450RPM Motors,
- 12" blade diameter capacity,
- 5/8" diameter belt driven saw arbors,

Non-staggered blade movement, not for notching, only approx. 7" of travel is necessary to complete the stroke of the saw blades.
Simultaneously cuts a left and right 45 degree miter with each cycle of the machine thus wasting little material. Leaves hands free to hold the material.
Easy to regulate the cutting speed. The counterbalanced saw heads return automatically. The saw blades extend beyond the fence line when cycling, cutting completely through the material.
Foot pedal operated, actuated by air. Scrap discharges to the bottom of the machine.
Air filter, regulator, lubricator.
Magnetic push button starters

UE-101422D-3 Inglet Verdi Basic 96" Panel Saw

Video of Machine in Operation

***Manufacturer's Information:

The Verdi Basic vertical saw is designed to cut any type of rigid material up to a height of 305 cm and a maximum thickness of 20 mm. The easy-to-use mechanism, combined with its powerful engine, turn the machine into an essential vertical saw for any workshop.

The Verdi Basic comes standard equipped with a universal saw. This is guided by a robust and reliable linear bearing guide system that eliminates any vibration and guarantees a straight and perfect cut all the way through.

It is available in 5 different sizes: in the 122 cm (48") and 157 cm (61.8") models the blade is manually operated. In the 210 cm (82.7"), 244 cm (96.1") and 305 cm (120.1") models the movement is automatic via a belt-driven mechanism.

Materials cut by the Verdi Basic vertical disc cutter:

- PVC foamboard
- Aluminium composite / Dibond®
- Aluminium sheets / ChromaLuxe®
- Acrylics / Plexiglas®
- MDF / Wood or Corrugated plastic.

Cutting features:

- RIGIDS Saw
- PVC foamboard 20 mm
- Aluminium composite / Dibond® 12 mm
- Aluminium sheets / ChromaLuxe® 3 mm
- Acrylics / Plexiglas® 12 mm
- MDF / Wood 20 mm

SEMI-RIGIDS Saw
Corrugated plastic 20 mm

Other features:

- Saw blade automatically returns to the upper position after each cut.
- Two measurement stops to accurately set up the desired measure to get.
- Laser system available as an accessory, useful to indicate the cutting line.
- All models provided with adjustable legs system.

Technical Specifications:

- Saw operation: Electronic
- Saw advancement: Automatic
- Saw Blade: 250 x 30 mm
- Cutting max height: 244 cm (96")
- Cutting max thickness: 22 mm
- Engine power: 1.5 HP
- Engine speed: 2700 RPM
- Voltage: 220 V / 110 V
- Dimensions: 345 x 250 x 50 cm
- Weight: 178 kg / 393 lb

UE-101422D-4 Curtis 10HP Compressors Model HT171-123

From the Seller: "This compressor has a new motor and magnetic starter. The pump is only two years old".

UE-101422D-5 Curtis 10HP Compressors Model HT171-123-8

From the Seller: "This compressor has a new compressor pump and new magnetic switch."
