Equipment Lot: Geo Knight MAXI-3242AT Twin Shuttle Press, Tennsmith Pneumatic 52" Shear & Fletcher AMP Alfamachine VN144 (U400) Joiner

SKU: UE-020322I
Manufacturer: Equipment Lot
Date listed: February 3, 2022

Equipment Lot: Geo Knight MAXI-3242AT Twin Shuttle Press, Tennsmith Pneumatic 52" Shear & Fletcher AMP Alfamachine VN144 (U400) Joiner



Available Items in Lot:
  • SKU # UE-020322I-1 Geo Knight MAXI-3242AT Twin Shuttle Press (Top Heat)
  • SKU # UE-020322I-2 Tennsmith Pneumatic 52" Shear



Sold Items in Lot:
  • SKU # UE-020322I-3 Fletcher AMP Alfamachine VN144 (U400) Joiner (SOLD)



From the Seller: "All equipment in this lot are in good working condition unless otherwise specified below."



*Items in this lot can be purchased individually or as a grouping.

GET PRICING

About this Item

Features & Specifications

UE-020322I-1 Geo Knight MAXI-3242AT Twin Shuttle Press (Top Heat)

From the Seller: "It has only been used a few times, practically new. It is disassembled on one side to save space, but we have the parts and it slides well when assembled."

***Manufacturer's Information:

The MAXI PRESS AIR is an Automatic large format heat transfer press intended for more automated and higher pressure needs than the Manual version. The MAXI PRESS AIR provides an oversized platen & a better production-oriented press with a single front loading table and high pressure pneumatic lifting system.

This pressure system is powered by a dual air-bag, 10-ton, 20,000 lbs max force self leveling mechanism. The press is activated with a push of a button, and automatically releases at the end of the timing cycle. The front console features the Digital Knight control, regulating digital temperature and digital automatic timing control, as well as full air pressure regulation.

The heavy steel triple reinforced welded C-Frame design is built to withstand a lifetime of intense pressing and automatic operation, and allows for full draping of materials over the front, left and right sides of the press, without hindrance. For a large format heavy pressure automatic press that is one step below the larger industrial 931 Triton machines, the MAXI PRESS AIR is the solution.

Features:

- Available in Single shuttle (standard) or Dual loading table format (optional)
- SuperCoil-Microwinding heater technology
- Ultra thick heater block assembly
- Solid steel pressure bars
- Heavy steel frame structures
- 20,000 lbs force, 10-ton air bag lift mechanism
- Self leveling pressure system
- Solid lower platen base
- Solid loading bed with ultra thick nomex padding
- Dual button easy-activate safety circuit
- Heavy duty locking casters for easy movability and solid foundation support
- Automatic press, release, temp & timer controls

Warranty:
- FREE LIFETIME Tech Support!

Specs:
- Minimum Compressed Air Required: 20gal, 4cfm, 100psi, 3/8" line
- Electrical for 44?64: 208V-230V, 18000W, 1PH, 85A, 100A breaker recommended (3ph/18KW/50A optional add $375)
- Electrical for 32?42: 208V-230V, 9000W, 1PH, 42A, 50A breaker recommended


UE-020322I-2 Tennsmith Pneumatic 52" Shear

From the Seller: "Used a handful of times, practically new."


UE-020322I-3 Fletcher AMP Alfamachine VN144 (U400) Joiner
(SOLD)

From the Seller: "In good working order. Nail heads not included."

Bought new: March 2015
Serial #: 65843

Video #1 of Machine in Operation

Video #2 of Machine in Operation

***Manufacturer's Information:

(Formerly labeled AMP VN144 )

The U-400 has been designed for ease of operation and is particularly well suited for joining large frames up to 5 1/2" (140mm) in width.

Supplied with a tilting floor stand, the machine can be operated from the front or back and has a single stage pneumatic foot pedal that activates the Horizontal Clamp, securing moulding during the joining process.

After the framer sets the two position stops for measuring the max distance between strokes, a dual function hand lever is then used to position and actuate both the Vertical Mould Holding Clamp and the V-Nail driver inserting V-Nails anywhere along the pre-set stroke distance.

A key operating feature for the U-400 allows the operator to quickly change V-Nail mm size using an interchangeable metal magazine channel. Operator easily accesses the interchangeable channel from the rear of the machine to load the appropriate V-Nail size. This feature eliminates the added purchased cost of plastic nail cartridges.

Unique Performance Features:

- Handles up to 5 1/2" (140mm) wide moulding – Unique competitive advantage over other industry frame joiners
- Designed with "interchangeable channel magazines" allowing operator to quickly change V-Nail sizes
- Operator controlled arm for left or right operations – allows framer to accurately position the Nail Head for inserting or stacking V-Nails anywhere along the frame joint
- Uses both a vertical and horizontal clamping method
- Adjustable working table height for operator comfort
- Easy table tilt adjustment
- Join either from back or front of machine

Frame Joining Capabilities

- Moulding Width (min to max): 1/4" up to 5 1/2" (6 - 140mm)
- Moulding Height (min to max): 1/4" up to 3 1/4" (6 - 80mm)
- Max Distance Between Vnails: 7 7/8" (200mm)
- Pre-set V-Nail Position Stops: Multiple
- V-Nail Sizes: 5mm, 7mm, 10mm, 12mm, 15mm (SW-HW-MDF)
- V-Nail Channel Capacity: 220 V-nails/channel

Machine Dimensions & Weight

- Length: 23 3/4" (600mm)
- Width: 15 1/4" (590mm)
- Height: 53" (1350mm)
- Weight: 198 lbs (90kg)

Power Requirements:

- Compressed Air 4NI at 5 Bar
- CE Compliant

***Concerning "Used" Items: Although we strive for accuracy, some specifications are provided to us by the Seller. Cross-check with manufacturer for any difference between the machine being sold and what is stated in the manufacturer's information. Descriptions of condition of the equipment are not warranties. Descriptions are intended only as a courtesy and their accuracy is not guaranteed. Buyer inspection encouraged. There are no warranties or guarantees implied unless otherwise stated. All items are sold "As Is, Where Is, and With All Faults." No guarantee is made as to fitness for a particular purpose, implied or otherwise. Feel free to contact us if you have further questions before purchasing.
