Fletcher 3100 63″ Multi Material Cutter (New) Item # NFE-136
Fletcher 3100 63″ Multi Material Cutter (New) Item # NFE-136
Fletcher 3100 63″ Multi Material Cutter (New) Item # NFE-136

New

Fletcher 3100 63" Multi Material Cutter

SKU: NFE-136
Manufacturer: Fletcher-Terry

New w/ Factory Warranty

From the Manufacturer:

The Fletcher 3100 Multi-Material Cutter is a versatile Wall Cutter designed with an interchangeable cutting head platform that uses multiple cutting blades, scoring tips and cutting wheel holders for cutting and scoring a large variety of materials. Handles material sheets up to 63"" high (1.6m) and features an acrylic breakout function. Mounts on wall or freestanding installation.

Purchase Package:

  • (4) Pillar Posts (Mat/Formboard, Plastic, MDF, Glass), (10) Mat/Foamboard Blades, (10) Plastic Blades, (10) Steel 120 degrees Glass Wheel Units
  • (1) MDF Cutting Wheel Set, (4) Wall Mounting Brackets, (1) 3100 Measuring Stop, (1) Manual

Interchangeable Cutting Head Technology:
Knife cutting blades and cutting wheels are manufactured to Fletcher specification requirements resulting in:

  • Better life and cutting performance
  • Blade to blade consistency
  • The elimination of ""blade deflection"" when cutting harder substrates

Multi-Material Cutting Capabilities:

  • Glass Up to 1/4"" (6mm)
  • PVC Up to 1/4"" (6mm)
  • Plastics & Acrylics Up to 1/4"" (6mm)
  • Aluminum Sheets Up to .040""
  • MDF Up to 3/32"" (2.4mm)
  • ACM Up to .078"" (2mm)
  • Gator Board Up to 1/2"" (13mm)

NFE-136-04-715

GET PRICING

About this Item

Features & Specifications

\nPurchase Package:?

  • Interchangeable Cutting Head Technology
  • Cuts clean, debris-free, no secondary processing
  • Mounts on wall or free-standing
  • Cuts wide range of substrates
  • Vertical Cutting Capacity: 63" (1.6m)
  • Cutting Head: Rides on high tensile strength steel, hard chrome plated and polished, resulting in smoother gliding action for consistent cutting head performance and longevity.
  • Vertical Bars: Rails do not bend or flex during the cutting process for straight, accurate cutting over the entire substrate height.
  • Material Clamping System: Patented lever-type clamping system that secures in place substrate heights up to 60" (152cm) to prevent buckling and shifting of material during the cutting process.
  • Machine Dimensions: Height: 78"" (241cm); Width: 80"" (203cm); Depth: 17"" (43cm)
  • Weight: 90 lbs (41kg)
  • Wall Space: 42.6 (3.96sqm)
  • Cut Capacity: 63"" (160cm)
  • Shipping Weight: 100lbs. (45kg)

Additional Information

Options & Replacement Accessories

P/N Description
04-116 PVC Cutting Pillar Post (blades separate, see 05-711)
05-711 PVC Cutting Blades (10/tube)
05-715 MDF Cutting Wheel Set
05-716 Aluminum Cutting Wheel Set
05-004 Utility/Rail Cutter Blades (100/box)
04-101 Optional Mounting Stand
04-114 3100 Measuring Stop


  • Interchangeable Cutting Head Technology:



      • Knife cutting blades and cutting wheels are manufactured to Fletcher specification requirements resulting in:



          • Better life and cutting performance

          • Blade to blade consistency

          • The elimination of "blade deflection" when cutting harder substrates








    Multi-Material Cutting Capabilities:



      • Glass Up to 1/4? (6mm)

      • PVC Up to 1/4? (6mm)

      • Plastics & Acrylics Up to 1/4? (6mm)

      • Aluminum Sheets Up to .040?

      • MDF Up to 3/32? (2.4mm)

      • ACM Up to .078? (2mm)

      • Gator Board Up to 1/2? (13mm)




    Unique Performance Features:



      • Interchangeable Cutting Head Technology

      • Cuts clean, debris-free, no secondary processing

      • Mounts on wall or free-standing

      • Cuts wide range of substrates




    Technical Specs:



      • Vertical Cutting Capacity: 63" (1.6m)

      • Cutting Head: Rides on high tensile strength steel, hard chrome plated and polished, resulting in smoother gliding action for consistent cutting head performance and longevity.

      • Vertical Bars: Rails do not bend or flex during the cutting process for straight, accurate cutting over the entire substrate height.

      • Material Clamping System: Patented lever-type clamping system that secures in place substrate heights up to 60" (152cm) to prevent buckling and shifting of material during
        the cutting process.




    Machine Dimensions:



      • Height: 78" (241cm)

      • Width: 80" (203cm)

      • Depth: 17" (43cm)

      • Weight: 90 lbs (41kg)

      • Wall Space: 42.6 (3.96sqm)

      • Cut Capacity: 63" (160cm)

      • Shipping Weight: 100lbs. (45kg)




    This item is shipped by freight company. Please request a shipping quote if needed.
