Gravotech IS7000 CNC Engraving Machine
SKU: GV-108010
Manufacturer: Gravotech
New w/ Factory Warranty
From the Manufacturer:
IS7000: The large format CNC engraving machine
Fast, powerful, and precise: discover a CNC engraving machine, unique in the market. The ISx000 range, a large cutter that's designed for large format jobs to batch engraving and cutting or used as a sign engraving machine or metal plate engraver.
HIGH-PERFORMANCE LARGE CUTTER
Developed from a monobloc structure the ISx000 range is a solid workhorse. A choice between 4 high frequency motors means that you will be working with the highest performance as a sign making machine, metal plate engraver, or letter cutting machine, no matter the thickness of the material.
INDUSTRIAL CUTTER
These large format rotary engraving machines makes high volume jobs quicker and easier. The ISx000 rotary engraving machines remains unrivalled on the ratio price per working area, on the market. Once you have set up the job on Gravostyle, you can trust this industrial cutter to do the task safely without constant supervision.
CNC ENGRAVING MACHINE
3 different sizes, 2 motorized axis (stepper or brushless motors) and a large range of accessories. Light and deep engraving, letter cutting, batch labelling, drilling, and 2.5 milling (hot iron) the ISx000 range is versatile enough to be used in most industrial applications.
About this Item
Features & Specifications
ADA and Braille Sign Engraving Machine
With our ADA compliant Braille solution, the ISx000 range becomes the sign making machine. From Gravostyle transcribing text to braille, the machine drills the plates and lays the beads automatically, the process is simple, hassle free and braille certified.
Batch Engrave For High Productivity
The large marking area is designed to both engrave big items, one by one or to do batches of hundreds of smaller items at one time, use the Stamp Mode to engrave different designs, use the Matrix Mode to duplicate patterns on labels. Applications such as a letter cutting machine and a sign making machine.
2,5 D Engraving and Drilling
Be it for hot stamp, insert manufacturing and even anti-counterfeit deep marking firearms, the ISx000 range will become your go to solution. Harder metals like metal plates can be processed by adding a lubrication kit, powerful spindle and the right cutting tools.
Applications
Signage
- Plastic Engraving
- POP Displays & Sign Engraving
- Express Engraver
- Wood Cutting & Engraving
- PMMA, Plexiglas® Acrylic Engraving
Creative
- Metal Engraving
- POP Displays & Sign Engraving
- Wood Cutting & Engraving
- PMMA, Plexiglas® Acrylic Engraving
- Steel Engraving
Manufacturing
- Steel Engraving
- Stainless Steel Engraving
- PMMA, Plexiglas® Acrylic Engraving
Additional Information
Technical Specifications
- 3 engraving areas available
- Clearance and open build: allow for larger sized materials to be used, limited only by your workspace.
- Powerful motors to choose from:
- The IQ step motor
- The XP with a DC motor
- Up to the XP milling solution with a 1000W DC motor capable of handling the most demanding jobs.
- A large and diverse range of accessories: from ADA compliant braille system to chip collection system allowing no clean-up needed.
- Technologies: Rotary, scribing
- IS7000 Marking area max: 610 mm (24 in) x 815 mm (32 in)
- Spindle power: 90W or 200W (Optional spindles: 150W, 750 W, 1kW)
- Max object height: 80 mm (3.1 in)
IS7000
- Max. object size (L x W x H) (weight): Unlimited x unlimited x 80 mm (3.15 in) (40Kg - 88.19 lbs)
- Dimensions (L x W x H): 1093 mm (43.03 in) x 1420 mm (55.90 in) x 735 mm (28.93 in)
- Machine weight: 220 kg (485.02 lbs)
- Automatic Z axis: No
- Noise level: 80 dB (A) +/- 2
- Spindle Type: Top load spindle or collet spindle
- Point & shoot: Yes
- Operating Temperature: 5° C (41° F) - 40° C (104° F)
- Connection to computer: USB
- Maximum speed: IQ: 25 mm/s (0.98 in/s) / XP: 60 mm/s (2.36 in/s)
- Z stroke (Z travel): 80 mm (3.15 in)
- Rotation speed: Max 20,000 rpm
- Software: Gravostyle
- Tool diameter:Â 4.36mm (0.17 in) with optional spindle: 3mm (0.11 in) to 6.36 mm (0.25 in)
