Cantek FL03 Fully Automatic Finger Jointer

Features:

- Three initial infeed tables lead to a fully automatic operation from feed to pre-press assembly stand
- F-C05 and F-C06 finger shapers perform automatic scoring, trimming, shaping, and gluing
- F-D01 enables automated workpiece feeding, aided by a steel brush roller that gently flips materials one by one into the pre-press assembly stand
- With the choice of 10 feet or 20 feet in length the F-T03/F-T05 chain type pre-press ensures accurate vertical and horizontal alignment before workpiece is cut to length
- Synchronized jointing and cutting is performed in a 2-step process within the F-A03 assembly press by employing two hydraulic cylinders at the front and rear to provide an extremely consistent joint

Specifications:

Includes the following:

F-I01 Multi-Stage (Three) Initial Conveyor Tables

- Auto Feeding Table: 650 mm (25.6“)
- Brush Wheel Drive Motor: 1 HP x3
- Machine Dimension (L x W x H): 3190 x 870 x 970 mm (126 x 35 x 39”)
- Packing Dimension (L x W x H): 3300 x 970 x 1070 mm (130 x 35 x 43”)

F-C05 Automatic Finger Shaper – Right End

- Max. available width working table: 650 mm (25.6”)
- Range of workpiece length: 150~1000 mm (5.9~39.4”)
- Range of workpiece height: 30~160 mm (1.2~6.3”)
- Table moving speed: 66 FPM
- Trimming saw speed: 2800 RPM, 3400 RPM
- Finger cutter speed: 5000 RPM
- Scoring saw speed: 2800 RPM, 3400 RPM
POWER REQUIRED
- Table-drive motor: 1/2 HP
- For conveyor motor: 1/2 HP
- Scoring saw motor: 1 HP
- Trim saw motor: 10 HP
- Shaper cutter motor: 20 HP
- Dia of Cutter (in/out): ø70 / ø160 mm (ø2.8 / ø6.3)
- Dust hood outlet diameter: 6” x 2”
- Machine dimensions (L x W x H)" 3670 x 2155 x 1905 mm (145 x 85 x 75”)
- Noise Value: 88.2 Db
- Packing dimensions (L x W x H): 3810 x 2270 x 2120 mm (150 x 90 x 84”)

F-C06 Automatic Finger Shaper – Left End

- Max. available width working table: 650 mm (25.6”)
- Range of workpiece length: 150~1000 mm (5.9~39.4”)
- Range of workpiece height: 30~160 mm (1.2~6.3”)
- Table moving speed: 66 FPM
- Trimming saw speed: 2800 RPM, 3400 RPM
- Finger cutter speed: 5000 RPM
- Scoring saw speed: 2800 RPM, 3400 RPM
POWER REQUIRED
- Table-drive motor: 1/2 HP x2
- For conveyor motor: 1/2 HP
- Scoring saw motor: 1 HP x 2
- Trim saw motor: 10 HP
- Shaper cutter motor: 20 HP
- Dia of Cutter (in/out): ø70 / ø160 mm (ø2.8 / ø6.3)
- Dust hood outlet diameter: 6″ x 2”
- Machine dimensions (L x W x H): 4160 × 2155 × 1905 mm (164 x 85 x 75”)
- Noise Value: 88.2 Db
- Packing Dimensions (L x W x H): 4855 x 2270 x 2120 mm (192 x 90 x 84”)

*1: The standard gluing device is roller TYPE; the tenon depth is 12 mm
*2: Inject/spray type gluing system can be installed upon request
*3: Device options for glues other than standard PVAc glue (PU, MUF, EPI, etc.) upon request

SPECIFICATIONS:

- With 20 HP for Main Spindle
- With 10 HP for Trimming Saw
- With Top and Bottom Scoring Saw, 1 HP x 2
- With 1/2HP (3Ph) for Feeding Conveyor

*Additional units to expand the system are available upon request.

F-D01 Automatic Feeding Table

- Auto Feeding Table: 650 mm (25.6”)
- Table Height: 860 mm
- Range of Material Length: 100~1000 mm (3.9~39.4”)
- Range of Material Width: 30~160 mm (1.2~6.3”)
POWER REQUIRED
- Feed Drive Motor: 1 HP
- Outfeed Drive Motor: 2 HP
- Brush Wheel Drive Motor: 1/8 HP
- Overall Length: 1540 mm (61”)
- Overall Width: 1545 mm (61”)
- Overall Height: 2450 mm (97”)

F-T03 Chain drive pre-press assembly stand

- Available length of workpiece: 6000 mm (237”)
- Available width of workpiece: 15~200 mm (0.60~7.9”)
- Available height of workpiece: 15~100 mm (0.60~4”)
- Feeding speed: 263 FPM
- Capacity length product: Max. 4 – 5 PCS/min
POWER REQUIREMENT
- Feed motor: 2 HP
- Machine dimensions (L x W x H): 6035 x 1000 x 1060 mm (238 x 40 x 42“)
- Noise level: 70 Db
- Packing dimensions (L x W x H): 6070 x 1120 x 1275 mm (239 x 44 x 51“)

F-A03 Assembly Press

- 6 m (20 ft) || 6.8 m (22 ft)
- Available Length of Workpiece: 6200 mm (20 ft) || 6800 mm (22 ft)
- Available Width of Workpiece: 15~160 mm (0.6~6.1”) || 15~160 mm (0.6~6.1”)
- Available Height of Workpiece: 15~60 mm (0.6~2.4”) || 15~60 mm (0.6~2.4”)
- Finger Assembly Pressure: 0~331 lbs/cm² || 0~331 lbs/cm²
- Feeding Speed: 263 FPM || 263 FPM
- Capacity Length Product: 5 PCS/min || 5 PCS/min
POWER REQUIRED
- Hydraulic Power Unit: 7 ½ HP || 7 ½ HP
- For Feeding: 2 HP || 2 HP
- For Sizing Saw: 5 HP || 5 HP
- Saw Arbor Diameter: ø1″ (ø25.4mm) || ø1″ (ø25.4mm)
- Dust Outlet Diameter: 101.6 mm (4”) || 101.6 mm (4”)
- Machine Dimension (L x W x H): 7670 x 1510 x 1370 mm (302 x 60 x 54”) || 8270 x 1510 x 1370 mm (326 x 60 x 54”)
- Noise Level: 84 Db || 84 Db
- Packing Dimension (L x W x H): 7745 x 1150 x 1585 mm (305 x 46 x 63”) || 8345 x 1150 x 1585 mm (329 x 46 x 63”)
