Used
Picture Framing Equipment Lot: Pistorius EMN-14 / EMN14 Double Miter Saws
SKU: UE-032623A
Manufacturer: Pistorius
Date listed: March 26, 2023
Picture Framing Equipment Lot: Pistorius EMN-14 / EMN14 Double Miter Saws
Available Items in Lot:
- UE-032623A-2 Pistorius EMN-14 / EMN14 Double Miter Saw
- UE-032623A-3 Pistorius EMN-14 / EMN14 Double Miter Saw
- UE-032623A-5 Pistorius MN200 Double Miter Saw
- UE-032623A-6 Pistorius MN200 Double Miter Saw
Sold Items in Lot:
- UE-032623A-1 Pistorius EMN-14 / EMN14 Double Miter Saw (SOLD)
- UE-032623A-4 Pistorius EMN-14 / EMN14 Double Miter Saw (SOLD)
From the Seller: "Well maintained in good working order. Has new left & right spindles."
Includes:
- 72" infeed table
- 84" Measuring Table
- Choice of stop: Air or manual
About this Item
Features & Specifications
UE-032623A-1 Pistorius EMN-14 / EMN14 Double Miter Saw
(SOLD)
***Manufacturer's Information:
- Blade Capacity: 14"
- Maximum Cutting Height: 5"
- Maximum Cutting Width: 6"
- Motor HP (2): 2
- Electrical: 230/460V (Wired 230)/3PH
- Dust Outlet (2): 4"
- Variable Speed Pneumatic Feed Down for Saw Blades
- Foot Pedal
- (2) 14" Blades
- Side Scrap Discharge Chute
- Safety Guards
- Approx. Shipping Weight: 1750 Lbs.
- Approx. Shipping Dimensions: 48" L x 48" W x 59" H
UE-032623A-2 Pistorius EMN-14 / EMN14 Double Miter Saw
***Manufacturer's Information:
- Blade Capacity: 14"
- Maximum Cutting Height: 5"
- Maximum Cutting Width: 6"
- Motor HP (2): 2
- Electrical: 230/460V (Wired 230)/3PH
- Dust Outlet (2): 4"
- Variable Speed Pneumatic Feed Down for Saw Blades
- Foot Pedal
- (2) 14" Blades
- Side Scrap Discharge Chute
- Safety Guards
- Approx. Shipping Weight: 1750 Lbs.
- Approx. Shipping Dimensions: 48" L x 48" W x 59" H
UE-032623A-3 Pistorius EMN-14 / EMN14 Double Miter Saw
***Manufacturer's Information:
- Blade Capacity: 14"
- Maximum Cutting Height: 5"
- Maximum Cutting Width: 6"
- Motor HP (2): 2
- Electrical: 230/460V (Wired 230)/3PH
- Dust Outlet (2): 4"
- Variable Speed Pneumatic Feed Down for Saw Blades
- Foot Pedal
- (2) 14" Blades
- Side Scrap Discharge Chute
- Safety Guards
- Approx. Shipping Weight: 1750 Lbs.
- Approx. Shipping Dimensions: 48" L x 48" W x 59" H
UE-032623A-4 Pistorius EMN-14 / EMN14 Double Miter Saw
(SOLD)
***Manufacturer's Information:
- Blade Capacity: 14"
- Maximum Cutting Height: 5"
- Maximum Cutting Width: 6"
- Motor HP (2): 2
- Electrical: 230/460V (Wired 230)/3PH
- Dust Outlet (2): 4"
- Variable Speed Pneumatic Feed Down for Saw Blades
- Foot Pedal
- (2) 14" Blades
- Side Scrap Discharge Chute
- Safety Guards
- Approx. Shipping Weight: 1750 Lbs.
- Approx. Shipping Dimensions: 48" L x 48" W x 59" H
UE-032623A-5 Pistorius MN200 Double Miter Saw
- Includes: Mister, Vertical Holddowns, 96" Measuring Table, Air Stop, and Infeed Table
***Manufacturer's Information:
Pistorius Model MN-200 for cutting wood, aluminum, plastics and fiberglass
Specifications:
- Blade Capacity: 12"
- Blade Arbors: 5/8"
- Maximum Cutting Height: 2-5/8"
- Maximum Cutting Width: 3-3/8"
- Motor HP: 1.5(Each)
- Electrical: 220/440V(Wired 220)/3PH2-5/8"
- Max. height & 3-5/16" max. width cap,
- (2) 1.5HP,
- 230/460V,
- 3,450RPM Motors,
- 12" blade diameter capacity,
- 5/8" diameter belt driven saw arbors,
Non-staggered blade movement, not for notching, only approx. 7" of travel is necessary to complete the stroke of the saw blades.
Simultaneously cuts a left and right 45 degree miter with each cycle of the machine thus wasting little material. Leaves hands free to hold the material.
Easy to regulate the cutting speed. The counterbalanced saw heads return automatically. The saw blades extend beyond the fence line when cycling, cutting completely through the material.
Foot pedal operated, actuated by air. Scrap discharges to the bottom of the machine.
Air filter, regulator, lubricator.
Magnetic push button starters.
UE-032623A-6 Pistorius MN200 Double Miter Saw
- Includes: Mister
***Manufacturer's Information:
Pistorius Model MN-200 for cutting wood, aluminum, plastics and fiberglass
Specifications:
- Blade Capacity: 12"
- Blade Arbors: 5/8"
- Maximum Cutting Height: 2-5/8"
- Maximum Cutting Width: 3-3/8"
- Motor HP: 1.5(Each)
- Electrical: 220/440V(Wired 220)/3PH2-5/8"
- Max. height & 3-5/16" max. width cap,
- (2) 1.5HP,
- 230/460V,
- 3,450RPM Motors,
- 12" blade diameter capacity,
- 5/8" diameter belt driven saw arbors,
Non-staggered blade movement, not for notching, only approx. 7" of travel is necessary to complete the stroke of the saw blades.
Simultaneously cuts a left and right 45 degree miter with each cycle of the machine thus wasting little material. Leaves hands free to hold the material.
Easy to regulate the cutting speed. The counterbalanced saw heads return automatically. The saw blades extend beyond the fence line when cycling, cutting completely through the material.
Foot pedal operated, actuated by air. Scrap discharges to the bottom of the machine.
Air filter, regulator, lubricator.
Magnetic push button starters.
***Concerning "Used" Items: Although we strive for accuracy, some specifications are provided to us by the Seller. Cross-check with manufacturer for any difference between the machine being sold and what is stated in the manufacturer's information. Descriptions of condition of the equipment are not warranties. Descriptions are intended only as a courtesy and their accuracy is not guaranteed. Buyer inspection encouraged. There are no warranties or guarantees implied unless otherwise stated. All items are sold "As Is, Where Is, and With All Faults." No guarantee is made as to fitness for a particular purpose, implied or otherwise. Feel free to contact us if you have further questions before purchasing.
Pricing & Shipping
Interested in the product? Fill out the form or call us at 330-405-9421 for pricing and other information.
Product is located in Illinois. Customers can pick the machine up or have it shipped for an additional fee.
