Sorbini Verniciatrice Per Bord UV Edge Coating Machine

•


  From the seller: "As Taken From Service"




  Manufactured in 1996




  Throughfeed UV edge roll coat and vacuum coat finishing machine with (2) UV Lamps
  1st Station: Brush head sander/ Denibber
  2.4HP 280/ 480V 3 phase motor
  2nd station: roll coat applicator
  2/3 HP 230/ 460V 3 phase applicator motor
  1/3 HP230/ 460V 3 phase doctor roll
  3rd station: vacuum applicator unit
  2HP 230/ 460V 3 phase motor
  Unit can be rolled in/? out of line for cleaning on when not needed
  Built in tray for excess finish
  Diaphragm pump mounted on the same base
  4th station: (2) UV curing units w/ (2) lamps each
  Each is approx. 3kW and each has a ? HP 230/ 460V 3 phase exhaust blower motor
  Rubber padded feed chain with top mounted hold down feed rollers
  Variable speed feed driven by a 3HP 280/ 480V 3 phase motor
  Hand crank adjustments on the brush sander station and the roll coat applicator for vertical and horizontal movements
  Mechanical digital read outs on three stations
  2.3? max. edge coating thickness
  Feed conveyor speed from 31 to 115 fpm
  Free-standing control and electrical cabinet that houses controls for the feed belt, sanding units, edge roll, coat applicator, vacuum coater and UV lamps
  Variable speed control for feed conveyor
  Controls for ? cure and full cure on UV lamps
  Hours meter on UV lamps
  First unit: lamp 1 ? 25 hours, lamp 2- 25 hours
  Second unit: lamp 1 ? 25 hours, lamps 2 ? 23 hours
  Left includes an outboard panel support roller conveyor and a diaphragm pump for the roll coat applicator
  S/N: 56960277.0
