A Plus Automation A5-MemoTS Joiner

***Manufacturer's Information:

This machine has been designed for the production framer that requires high speed assembly and has frequent changeovers. Its technology is the state of the art and allows you to store an almost endless number of programs. The programs can be input by the operator or downloaded from a PC. After storing this information, the operator can select the frame to be produced via the touch screen or by scanning with the optional bar code reader. The machine will automatically adjust and production can restart immediately. The barcode scanner can also fully program the machine through the use of a special QR barcode. Wedges can be driven or stacked in up to 10 positions per corner. It is a very fast and reliable machine. It can be used to assemble all types of wood, plastic and MDF using our special steel A+ wedges, which are manufactured in several sizes. The horizontal, vertical and fence clamping devices provide a very precise tightening of the frames. A robust wedge driver provides trouble free operation.

Specifications:

- Frame Height (min. max.): 6mm - 107mm / 1/4" - 4 1/4"
- Frame Width (min. max.): 10mm - 110mm / 3/8" - 4 1/3"
- Wedge storage capacity: n. 220
- Standard wedges size: 7mm - 10mm - 15mm
- Optional wedge size: 3mm - 5mm - 12mm
- Pneumatic feed: Bar 5-7 / Psi 70-100
- Air consumption: 4 Nl at 5 BAR
- 0.14 cf3 at 73 Psi
- Power Supply 220V 50Hz / 110V 60Hz
- Weight: approx. 115 kg / 254 lbs
- Height of work bench: 970mm / 38"
- Overall dimensions: 880mm x 680mm x 1400mm
- 35" x 27" x 56"
