Fotoba Digitrim 64" X Cutter

***Manufacturer's Information:

The Fotoba Digitrim is a series of automatic, self-squaring cutters designed to trim digital prints with high precision using optical sensors and specialized cut marks. Unlike full XY cutters that trim both axes in one pass, the Digitrim typically requires two passes: one to cut rolls or sheets into strips (X-cut), and a second pass to finish the vertical edges (Y-cut).

Features:

- Automatic Squaring: The cutter uses digital sensors to detect "FOTOBA CUTMARKS" printed with the images, automatically compensating for any media misalignment during feeding.
- High Precision: According to Colex and Fotoba technical sheets, the Digitrim offers accuracy up to 0.1mm.
- Media Versatility: It can handle various flexible materials up to 0.5mm (20 mil) thick, including photo paper, vinyl, canvas, and laminated prints.
- Self-Sharpening Blades: The system uses rotary blades that are designed to be self-sharpening and self-cleaning for consistent performance.
- Memory Channels: Users can store up to five different cut mark data configurations for frequently used jobs.

Specifications:
(Based on Digitrim 64)

- Max Cutting Width: 163 cm / 64 inches
- Max Linear Speed: 18 meters per minute / 50 feet per minute
- Max Media Thickness: 0.5 mm / 20 mil
- Power Requirements: 115V AC, 15A (standard US)
- Weight: Approximately 378 lbs (main unit)
