Geo Knight MAXI-3242AT Twin Shuttle Press (Top Heat) (Used) Item # UE-082224A
Geo Knight MAXI-3242AT Twin Shuttle Press (Top Heat) (Used) Item # UE-082224A
Geo Knight MAXI-3242AT Twin Shuttle Press (Top Heat) (Used) Item # UE-082224A

Used

Geo Knight MAXI-3242AT Twin Shuttle Press (Top Heat)

SKU: UE-082224A
Manufacturer: Geo Knight
Date listed: August 22, 2024

Geo Knight MAXI-3242AT Twin Shuttle Press (Top Heat)

  • Model Number: MAXI-3242AT
  • Item Under Warranty: No
  • Can Item Be Inspected On-Site: Yes

From the Seller: "It has only been used a few times, practically new. It is disassembled on one side to save space, but we have the parts and it slides well when assembled."

GET PRICING

About this Item

Features & Specifications

***Manufacturer's Information:

The MAXI PRESS AIR is an Automatic large format heat transfer press intended for more automated and higher pressure needs than the Manual version. The MAXI PRESS AIR provides an oversized platen & a better production-oriented press with a single front loading table and high pressure pneumatic lifting system.

This pressure system is powered by a dual air-bag, 10-ton, 20,000 lbs max force self leveling mechanism. The press is activated with a push of a button, and automatically releases at the end of the timing cycle. The front console features the Digital Knight control, regulating digital temperature and digital automatic timing control, as well as full air pressure regulation.

The heavy steel triple reinforced welded C-Frame design is built to withstand a lifetime of intense pressing and automatic operation, and allows for full draping of materials over the front, left and right sides of the press, without hindrance. For a large format heavy pressure automatic press that is one step below the larger industrial 931 Triton machines, the MAXI PRESS AIR is the solution.

Features:

- Available in Single shuttle (standard) or Dual loading table format (optional)
- SuperCoil-Microwinding heater technology
- Ultra thick heater block assembly
- Solid steel pressure bars
- Heavy steel frame structures
- 20,000 lbs force, 10-ton air bag lift mechanism
- Self leveling pressure system
- Solid lower platen base
- Solid loading bed with ultra thick nomex padding
- Dual button easy-activate safety circuit
- Heavy duty locking casters for easy movability and solid foundation support
- Automatic press, release, temp & timer controls

Warranty:
- FREE LIFETIME Tech Support!

Specs:
- Minimum Compressed Air Required: 20gal, 4cfm, 100psi, 3/8" line
- Electrical for 44?64: 208V-230V, 18000W, 1PH, 85A, 100A breaker recommended (3ph/18KW/50A optional add $375)
- Electrical for 32?42: 208V-230V, 9000W, 1PH, 42A, 50A breaker recommended

***Concerning "Used" Items: Although we strive for accuracy, some specifications are provided to us by the Seller. Cross-check with manufacturer for any difference between the machine being sold and what is stated in the manufacturer's information. Descriptions of condition of the equipment are not warranties. Descriptions are intended only as a courtesy and their accuracy is not guaranteed. Buyer inspection encouraged. There are no warranties or guarantees implied unless otherwise stated. All items are sold "As Is, Where Is, and With All Faults." No guarantee is made as to fitness for a particular purpose, implied or otherwise. Feel free to contact us if you have further questions before purchasing.

Pricing & Shipping

Interested in the product? Fill out the form or call us at 330-405-9421 for pricing and other information.

Product is located in Colorado. Customers can pick the machine up or have it shipped for an additional fee.
