Norfield 1020 Casing Miter Saw

***Manufacturer's Information:

The Norfield Model 1020 (also known as the 1020K) is a heavy-duty, automatic double-ended casing saw designed for high-production trimming of door components. It is widely used in the pre-hung door industry to simultaneously cut both ends of casing material at either 90-degree or 45-degree angles.

Features:

- Production Speed: Operates at a rate of approximately 25 to 30 pieces per minute, depending on material and setup.
- Automatic Feeding: Features a flow-through design with an infeed hopper that allows standard profile casing to be stacked and fed automatically.
- Dual Saw Assemblies: Equipped with two high-speed 10-inch blades to trim both ends of the board simultaneously.
- Cutting Flexibility: Quickly adjusts between 90° and 45° cuts; some models include an undercut feature (up to 15 degrees) to match specific jamb edge.

Specifications:

- Feature Range / Requirement
- Casing Length: 1' 6" to 8' 0"
- Casing Width: Up to 3-1/2"
- Casing Thickness: 3/8" to 1-1/2"
- Blade Size: 10" industrial-quality carbide-tipped
- Electrical: 208/230V, 3-Phase, 60Hz, 30 Amp (standard)
- Air Supply: 22 CFM @ 90 PSI
- Weight: Approximately 1,600 lbs

Operational Highlights:

- User Controls: Front-mounted controls allow for easy adjustment of trim lengths and miter angles, minimizing setup time.
- Kerfing Option: Some units come equipped with a kerfing option, which adds functionality for specific door production needs.
