Premier Tech Stretch Hooder / Pallet Wrapping System

***Manufacturer's Information:

The CHRONOS Stretch Hooder efficiently secures pallet loads, wrapping them from top to bottom in one stroke, optimizing uptime efficiency.

The tight-fitting hood ensures load stability even when opened. It provides optimal outdoor protection against water, humidity, UV, and diverse weather conditions. The plastic film can be transparent or pre-printed with your logo, enhancing brand visibility at your customers’ sites.

Capable of securing various loads, including mixed, uneven, short, tall, heavy, and light, the pallet hooder requires minimal maintenance and is easy to operate.

Speed: up to 100 loads per hour*

Applications: bags, boxes, bottles, big bags, mixed loads, trays, and more

Features:

Optimal protection:
- Ensures weather-resistant loads
- Wraps tightly around various products and load sizes with up to 150% film elasticity
- Prevents film tails and loose film underneath the pallet

Ease of use:
- Automatically detects load heights and centers pallets on the conveyor
- Can accommodate multiple lines and various load sizes with stored recipes
- Mobile film-loading system lowers the film carriage to a safe working height
- Equipped with safety fences and interlocking doors

Cost-effective:
- Hoods up to 2000 loads per roll, offering extended autonomy compared to other technologies*
- Ensures consistent and minimal film consumption, providing stable operating costs
- Eliminates the need for top sheets
- Uses low air and power consumption
* More or less, depending on load and film characteristics

Options:
- Two-color continuous film printing (e.g., for a company name/logo)
- Sleeving, banding, and double-hooding
- Overheight compatibility to handle taller pallet loads
- Pallet infeed and outfeed conveying systems

Specifications:

Typical footprint:
305" L x 212" W x 182" H (7747 mm x 5385 mm x 4623 mm)

Stretch dimensions:
Up to 56" L x 46" W short side leading
(Long side leading option available)

Pallet load:
Height: up to 10' (3050 mm)
Weight: up to 4400 lbs (heavy-duty option available)

Electrical requirements:
480 V / 60 Hz

Operating temperature:
40°F to 104°F (5°C to 40°C)
