Hoffmann MU3-P Pneumatic Dovetail Routing Machine

Highlights:

This pneumatically controlled dovetail routing machine is the more automated version of the MU 3 and MU3-D models. Aside from the same attributes in terms of design and built quality, the machine features two pneumatic cylinders and a pneumatic foot pedal.

One short stroke cylinder is used to clamp the material the instant the foot pedal is pressed, while a second, larger cylinder is used to move the router carriage up and down.

The main benefits compared to the manual machines are faster and more comfortable operation, more consistent results due to set routing feed rates and the fact that both hands can remain on the material during the routing sequence. This is an important advantage when processing longer parts.

Standard Features:

Hoffmann Dovetail Routing Machine, model MU 3-P, ready for operation, with air regulator installed, W-2 solid carbide router bit installed, standard 45 degree center fence plate, center line locator and square stop, motor fine adjustment, parts storage, toolkit and manual.

Technical data:

- Power Supply: 120 volts - 7.4 Amps
- Air Supply: 90 psi - approx. 0.1 cubic foot/cycle
- Motor: 885 Watt motor with double front bearing
- Motor speed: 35,000 rpm at idle
- Collet size: 1/4"
- Motor carriage guides: 20mm diameter guide rods, precision ground
- Digital Display: dual liquid crystal display, 3/8" digit size, accurate to 0.004"
- Operation: pneumatic - dual cylinder design
- Max. height routing: 3 3/4" - 95mm / moulding 5 7/8" - 150mm
- Dust collection port: 2" - 50mm diameter
- Installed router bit: W-2, solid carbide
- Available router bits: W-0, W-1, W-2, W-3 (W-4 with optional larger motor)
- Dimensions W/D/H: 29 1/8" x 25 5/8" x 32 3/4" (without optional table extensions)
- Weight: 70.4 lbs.

Warranty:

One year on parts and workmanship.
