Cantek FL24 Semi-Automatic Finger Jointer

SKU: CT-106300
Manufacturer: Cantek

Stop losing untapped revenue by turning your wood waste into valuable material.

The Cantek FL24 Semi-Automatic Finger Jointer represents a state-of-the-art finger jointing production line, meticulously crafted to transform extra short wood waste into valuable materials, all the while upholding an exceptional balance between performance and cost-effectiveness. Its compact design with multiple automatic features and options makes it an ideal solution for a small sized finger jointing operation. By utilizing a solitary shaper setup, this system delivers extraordinary value in performance and affordability, positioning it as an enduring revolutionary force within the woodworking sector.

Why Cantek FL24 Semi-Automatic Finger Jointer?

Semi-automatic finger jointer with a small footprint
Excellent performance-to-cost ratio
Right/left finger shaper scores, profiles, and glues both right and left joints in a single machine
Workpieces automatically travel between profiling & gluing stations
Production speed: 2~3 cycles/min
Length of cut is calculated by an encoder and set on a touch screen for increased accuracy with a finished board tolerance of 0 to 0.08” (0 to 2mm)
Manual rotary table design turns pieces to allow processing of both ends on a single shaper system – optional automatic rotary table available
Optional automatic adjustment of the scoring blades and shaper section for left & right profiles
Presses available in various lengths to suit your production needs

Link to Video of the Machine

GET PRICING

Features & Specifications

Features:

- Applicable for machining extra short wood waste of 4” (100mm)
- Only two operators required for max production
- Hopper loader mounted for workpieces to automatically feed into the assembly press comes standard with the FL-24
- As standard we use PVAc glue, but we have optional gluing systems for PUR, MUF, EPI, etc. available upon request
- Synchronized jointing and length cutting is performed in a 2-step process within the F-A05 or A07 single stage automatic infeed finger assembler

Specifications:

Includes the following:

F-C03W01 Finger Shaper (Injection Glue System)

- Max. available width working table: 650 mm (25.6”)
- Range of workpiece length: 100~1000 mm (4.7~27.5”)
- Range of workpiece width: 20~60 mm (3.9~39.4”)
- Range of workpiece thickness: 30~160 mm (1.2~6.3”)
- Trimming saw speed: 2800/3400 RPM
- Finger cutter speed: 6000 RPM
- Finger cutter diameter (in/out): ø70 / ø160 mm (ø2.8 / ø6.3)
- Dust out diameter: 6 x 2”
- Machine dimensions (L x W x H): 4425 x 1815 x 1855 mm (175 x 72 x 73”)

POWER REQUIRED

- Table-drive motor (Infeed & Outfeed): 1/2 HP x2
- For conveyor motor: 1/2 HP x2
- Scoring saw motor (Top & Bottom): 2 HP
- Trimming saw motor: 5 HP
- Shaper cutter motor: 15 HP

* 1: Injection type glue applicator – using PVAc glue only
* 2: Finger cutters – 10 pieces
* 3: Comes with saw blades

F-D06-1.4 Roller Table

- Working size length: 150~1000 mm (5.9~39.4”)
- Working size width: 650 mm (25.6”)
- Machine dimensions (L x W x H): 1510 x 940 x 950 mm (60 x 37 x 38”)

F-A05/A07 Single Stage Automatic Infeed Finger Assembler
F-A05-4.5 or 6 || F-A07-4.5
- Max. working size length: 4500 mm (177.2”) or 6000 mm (236.2”) || 4500 mm (177.2”)
- Working size width: 30~160 mm (1.2~6.3”) || 30~160 mm (1.2~6.3”)
- Working size thickness: 20~60 mm (078~2.4”) || 20~60 mm (078~2.4”)
- Max. assembly press: 0~100 KG/CM² || 0~100 KG/CM²
- Dust outlet diameter: 4” || 4”
- Machine dimensions (L x W x H): 7065 x 2045 x 1430 mm (279 x 81 x 57”) || 7345 x 1835 x 1435 mm (290 x 73 x 73”)

MOTOR HORSEPOWER

- Material feeding motor: 2 HP || 1 HP
- Material feeding motor: 3 HP || 2 HP
- Sizing saw motor: 5 HP || 5 HP
- Hydraulic system motor: 5 HP || 5 HP

* 1: Comes with saw blades
* 2: Every output – one fixed length at a time
