OMGA V235 NC AUTOMATIC TWIN BLADE / DOUBLE MITRE SAW (NEW) Item # OM-101120

New

OMGA V235 NC Automatic Twin Blade Double Miter Saw

SKU: OM-101120
Manufacturer: OMGA

Fully Automatic CNC Mitering System with fixed blade angle. 14" saw blades. Complete with hopper feeder is ideal for high production situations in the photo frame, windows, door and kitchen cabinet components.

The system is well suited for elevated production of picture and photo frames as well as any other component which is assembled by way of mitering the ends. Sophisticated, but simple and practical, the system is fitted with a guidance computer which makes the machine more productive and flexible, for an improved quality of the finished product. The machine counts with a hopper feeder (available in both Horizontal and Vertical versions) which allows it to function completely unattended.

Key Features:

  • Optimized Cutting By inputting the data relating to the length of the moulding along with the cutting list, the machine is able to select the best sequence automatically, maximizing the material's yield.
  • Higher Production The high speed feed carriage allows large scale production in any circumstance. The zero setup time for changes in the cutting list, is another important factor in the high performance of this unique system. Depending on several variables the output of the system ranges from 1000 to 1500 pieces per hour.
  • Data Storage The computer has down loading capability through the 3 1/2" floppy disk or direct cable connection via RS 232 port. It is possible to interrupt the cutting process at any time and have a different program carried out, while all the data relating to the first program including the number of pieces still to be executed remain stored.
  • Easy User Interface The onboard PC with its 19" monitor, allows all the messages that the operator requires, to be fully and constantly displayed in the desired language. A step by step full graphic display makes it easy for the operator to select the required operation. The on the screen diagnosis , reduces needless down time due to electric or pneumatic failure.
  • Flexibility The two 14" saw blades make it possible to attain a considerable cutting capacity.
GET PRICING

About this Item

Features & Specifications

Features and Specifications:

- Max cutting width: 3 9/16"
- Max cutting height: 2 3/4"
- Motor power: 4 HP
- Saw blade bore: 30 mm
- Saw blades Diameter: 350 mm
- Overall dimensions: 98" x 33" x 63"
- Crated dimensions: 108" x 69" x 75"
- Crated dimensions Hopper: 98" x 29" x 43"
- Dust chute: 2 x 3"
- Max feed stroke: 47"

Additional Information

Options:
- Outfeed conveyor belt with kicker 1000 x 100 mm / 2000 x 100 mm
- Length sorting conveyor belt 3000 x 100 mm with 3 kickers
- Transfer conveyor belt with pneumatic feed step 2000 x 600 mm
- Vertical hopper feeder for moldings 3000 / 4000 / 5000 / 6000 mm.
- Horizontal hopper feeder with 2000 mm depth ramps for moldings 3000 / 4000 / 5000 / 6000 mm

Model V 235 NC is only suitable for square frames, being saw blades at a fix 90° angle.
A programmable numerical control with a 17” touch screen, allows the operator to follow operations step by step. USB and Ethernet ports are available for Input/Output and net connection.
The software also allows the reduction of waste by optimizing the length of the molding. A hopper feeder is available in various lengths for loading either vertical or horizontal. Outfeed conveyor belts can complete the system either with only one kicker for downloading cut pieces, or with three kickers for length sorting and downloading. The automatic cycle has not to be interrupted for loading new moldings.
