About this Item
Serial # 7T-61437
Fast and Easy Setups
It takes just seconds to change tab positions. Changing tab sizes takes only two minutes.
Handles Many Size Sheets
The extra long steel knives quickly and easily cut a 1 inch (25.4mm) tab in the first position on a 15 inch long sheet.
Precision Cut a Variety of Tab and Step Cuts.
Adjust tabs to any width from 1/2 inch to 6 inches
(12.7mm to 152.4mm) by simply moving knives closer or father apart.
Safe and Easy Operation
The full length safety bar protects the operator?s fingers from knives while rapidly inserting sheet after sheet.
Knives are made from tool steel, hardened and precision ground. They are mounted on 2 inch diameter steel arbor supported by ball bearings. Accurate cutting is further ensured by the solid cast-iron
The only regular maintenance required is to routinely fill the automatic lubricator.
Speed: Up to 5,000 tabs per hour
Sheet Size: Maximum:15 inches with a half inch inset on a 1 inch tab (381mm with a 12.7mm inset cut on
a 25.4mm tab) Minimum:any width x 5-1/2 inches (139.7mm minimum depth)
Paper Weight: 6-point to 25-point paper 6 inches (152.4mm) maximum 1/2 inch (12.7mm) minimum
Tab Cut Size: Stepcut: 13-1/2 inches (342.9mm) maximum 1/4?, 3/8?, 1/2?, 5/8?, 3/4?
Stock Tab Extensions: (6.3mm, 9.5mm, 12.7mm, 15.9mm, 19.1mm)
Knives: Hardened, precision ground steel
Electrical Requirement: 0.5 amp, 120 VAC, 50-60 Hz
Air Requirements: 2 cubic ft. per minute (944 cubic cm per second) at 80 lbs. pressure. Built in pressure
regulator and filter allow use of shop air or separate compressor. permits variations in cutting power.
Ball Bearings of Bushings: All Moving Parts
Lubrication: Fully Automated
Table Top: 48 inches x 15-3/4 inches x 3/8 inches (1219 mm x 400 mm x 9.5 mm)
Table Height: (Adjustable) 39-1/2 inches (1003.3 mm0 maximum 32-1/2 inches (825.5 mm) minimum
Floor Space Required: 58 inches x 26 inches (1473.2 mm x 660.4 mm)
Shipping Weight: 335 lbs. (152 kg)
***Concerning "Used" Items: Although we strive for accuracy, some specifications are provided to us by the Seller. Cross-check with manufacturer for any difference between the machine being sold and what is stated in the manufacturer's information. Descriptions of condition of the equipment are not warranties. Descriptions are intended only as a courtesy and their accuracy is not guaranteed. Buyer inspection encouraged. There are no warranties or guarantees implied unless otherwise stated. All items are sold "As Is, Where Is, and With All Faults." No guarantee is made as to fitness for a particular purpose, implied or otherwise. Feel free to contact us if you have further questions before purchasing.
This machine can be picked up in Ohio or shipped for an additional fee.
UE-070522D - 052422000202A
Scotty 10000 / Scott Precision
*** Although we strive for accuracy, some specifications are provided to us by seller. It is a good idea to double check specifications by manufacturing company for possible errors of information. Feel free to call us if you have further questions before purchasing.
Pricing & Shipping
Interested in the product? Fill out the form or call us at 330-405-9421 for pricing and other information.
Product is located in Ohio. Customers can pick the machine up or have it shipped for an additional fee.
