Cassese MACH 4 Cart Memory Underpinner

SKU: LS-101010
Manufacturer: Cassese

*NO LONGER AVAILABLE

Click Here for a Comparable New Underpinner
SKU: FT-102040 Fletcher AMP U-500 Single Channel - Single Level - Programmable Joiner
SKU: FT-102045 Fletcher AMP U-500 Single Channel - Multi-Level - Programmable Joiner

Contact our office for used options.

New w/ Factory Warranty

The Cassese Mach 4 Cart electronic pneumatic memory joiner delivers fast performance and heavy duty design for high production, programmable memory with a user friendly touch-screen interface and of course, Cassese quality corners! Touchscreen tells operator which cartridge size and accessories to use. Stores up to 3000 profiles in memory. ?Unlimited profiles if full parameter barcode and scanner used. Very fast! Up to 3300 cycles per hour.

The MACH 4 Cart uses Cassese nails in cartridges, which means no adjustment to machine when changing nail size.

Electronic + Pneumatic memory joiner

GET PRICING

About this Item

Features & Specifications

-High Speed 3300 cycles / hour (2 nails / corner)
-Cassese’s exclusive Smart Wedge Drive System eliminates the need to adjust the top clamp location and eliminates the need to adjust air pressure between Hardwood and Softwood.
-9 nailing positions, up to 9 nails per position
-Storage for 3,000 moulding profiles
-Wide Mouldings 7 ½” stroke
-Super powerful retractable Ultra clamps draw moulding tight
-Barcode ready

Additional Information

Mouldings:

-Width: 1/4” 6” (5mm-150mm)
-Height: 5/16” 4”7mm-100mm)
-Net Weight: 213 lbs (97kg)
-Minimum Frame Dimensions: 3 5/16” x 3 5/16” (85mm x 85mm)
-Stroke Length: 7 ½” (190mm)
-Dimensions: L 23” (584mm) W 26 ¼” (666mm) H 46” (1168mm)

Pricing & Shipping

Shipping Notice: Unless specified on the product, items are FOB Origin. It is the responsibility of a customer to pickup, either personally or by a contracted shipping agent, their product.

Interested in the product? Fill out the form or call us at 330-405-9421 for pricing and other information.
